T-MOTOR AT12A 2-3S Fixed-Wing ESC
$39.00
AT Series for fixed-wing aircraft. The T-MOTOR AT12A is an official 2-3S LiPo fixed-wing electronic speed controller rated at 12 A continuous and 15 A peak current.
Key Features
- Exact manufacturer SKU AGT01010007.
- 2-3S LiPo input range with 12 A continuous current.
- 15 A manufacturer-listed peak current.
- Linear BEC, 5 V / 2 A.
- Official size 38 x 18 x 7 mm; source-listed weight 11 g.
Specifications
| Manufacturer SKU | AGT01010007 |
|---|---|
| Battery range | 2-3S LiPo |
| Continuous current | 12 A |
| Peak current | 15 A |
| BEC | Linear BEC, 5 V / 2 A |
| Dimensions | 38 x 18 x 7 mm |
| Weight | 11 g |
| Manufacturer matching guide | AM40 V2 and AM60 V2 motors |
What's Included
One T-MOTOR AT Series ESC and one manufacturer-listed hardware kit. Motor, propeller, battery, receiver, servos, programming accessories, connectors not shown as attached, and other aircraft components are sold separately.
Integration and Safety
Confirm battery voltage, motor current, BEC load, throttle signal, wiring, connectors, cooling, mounting, and aircraft requirements before use. Follow the current manufacturer instructions and do not transfer ratings between AT models.
AT Series
Specifications and technical data
Official model-specific reference material
Selected configuration
AT12A
Manufacturer SKU AGT01010007
| Manufacturer SKU | AGT01010007 |
|---|---|
| Series | AT Series |
| Application | Fixed-wing UAV / aircraft |
| Battery range | 2-3S LiPo |
| Continuous current | 12 A |
| Peak current | 15 A |
| BEC | Linear BEC, 5 V / 2 A |
| Dimensions | 38 x 18 x 7 mm |
| Weight | 11 g |
| Manufacturer matching guide | AM40 V2 and AM60 V2 motors |
| Package contents | 1 x ESC; 1 x hardware kit |
03
Manufacturer reference
